SVN-SLA solar water heater
SVN-SLA solar water heater
Thông tin chi tiết
Galvanized steel type compact Non-pressurized Solar Water Heater
SVN-SLA Model is the most popular solar water heater that with reliable and affordable price. It uses high efficiency vacuum tubes and mature technology that makes it’s life-span more than 15 years. Furthermore it suits for both flat and declined roof and most of the climates.
Details:
1) Reliable and efficient with twin-glass solar tubes
2) Easy plug-in installation
3) Outer tank material: powder coating or galvanized steel.
4) Inner tank material: 0.5mm thick SUS304 food grade stainless steel plate
5) Frame material: 1.5mm galvanized steel
6) Superior heat preservation ensured by 50 - 65mm polyurethane foam insulation layer
1) Reliable and efficient with twin-glass solar tubes
2) Easy plug-in installation
3) Outer tank material: powder coating or galvanized steel.
4) Inner tank material: 0.5mm thick SUS304 food grade stainless steel plate
5) Frame material: 1.5mm galvanized steel
6) Superior heat preservation ensured by 50 - 65mm polyurethane foam insulation layer
|
Item No.
|
Specification
|
Tank's Capacity
|
Tank and solar tubes' Capacity
|
Effective collector
area m2 |
|||
|
Diameter of outside tank
|
Qty. of solar tubes
|
Diameter of solar tube
|
Length of solar tube
|
||||
|
SLA-2-42154715
|
Ø420mm
|
15pcs
|
Ø47mm
|
1.5m
|
84.2L
|
104.4L
|
1.45
|
|
SLA-2-42184715
|
Ø420mm
|
18pcs
|
Ø47mm
|
1.5m
|
100.5L
|
124.7L
|
1.76
|
|
SLA-2-42204715
|
Ø420mm
|
20pcs
|
Ø47mm
|
1.5m
|
111.4L
|
138.3L
|
1.97
|
|
SLA-2-42244715
|
Ø420mm
|
24pcs
|
Ø47mm
|
1.5m
|
133.3L
|
165.5L
|
2.38
|
|
SLA-2-42304715
|
Ø 420mm
|
30pcs
|
Ø 47mm
|
1.5M
|
160.0L
|
206.3L
|
3.00
|
|
SLA-2-47155818
|
Ø 470mm
|
15pcs
|
Ø 58mm
|
1.8M
|
132.3L
|
172.9L
|
2.01
|
|
SLA-2-47185818
|
Ø 470mm
|
18pcs
|
Ø 58mm
|
1.8M
|
148.6L
|
197.3L
|
2.45
|
|
SLA-2-47205818
|
Ø 470mm
|
20pcs
|
Ø 58mm
|
1.8M
|
164.9L
|
219.0L
|
2.74
|
|
SLA-2-47245818
|
Ø 470mm
|
24pcs
|
Ø 58mm
|
1.8M
|
197.5L
|
262.5L
|
3.32
|
|
SLA-2-47305818
|
Ø 470mm
|
30pcs
|
Ø 58mm
|
1.8M
|
246.3L
|
327.5L
|
4.18
|
|
Item No.
|
SVN-SLA
|
Trademark
|
|
|
Place of Origin
|
China
|
Price Terms
|
FOB, CFR ,CIF
|
|
Payment Terms
|
T/T, L/C
|
Minimum Order
|
100 units
|
|
Supply Ability
|
4,500 units/month
|
Delivery Time
|
15 days
|
|
Certificate
|
CE,ISO9001,CCC,SRCC
|
OEM Supply Y/N
|
Yes
|
