Specifications

Inverter Output Specifications:

• Continuous Output Power: 10000 Watts
• Surge Rating: 30000 Watts (20 Seconds)
• Output Waveform: Pure Sine/Same as input (Bypass Mode)
• 100-110-120Vac / 220-230-240Vac
• Nominal Efficiency: >88% (Peak)
• Line Mode Efficiency: >95%
• Output Frequency: 50Hz +/- 0.3Hz / 60Hz +/- 0.3Hz
• Typical Transfer Time: 10ms (Max)
• THD: < 10% DC

Input Specifications

• Nominal Input Voltage: 48.0Vdc
• Low Battery Alarm: 42.0Vdc-44.0Vdc
• Low battery Trip: 40.0Vdc-42.0Vdc
• High Voltage Alarm: 64.0Vdc
• Low battery Voltage Restart: 62.0Vdc
• Idle Consumption: 3.125 amps DC
• Power Saver Mode Idle Consumption: <0.73 amps DC

Charger Specifications

• Output voltage: Depends on battery Type
• Charger Rate: 100A

Dimensions

• Unit Weight: 145.5 lbs.
• Unit Size L x W x H: 23.3 x 16.3 x 7.9 inches
• Shipping Weight: 190 lbs.
• Shipping L x W x H 30 x 21.25 x 15.25 inches
